Description
Laser Pump Cavity Ceramic Reflector
The ceramic reflector green body is made of 99% Al2O3, and the green body is fired at an appropriate temperature to retain proper porosity and proper green strength. The surface of the reflector is fully coated with high-reflectivity ceramic glaze. Compared with the gold-plated reflector, the biggest advantage lies in its extremely long service life and diffuse reflection.
Main features:1. Dimensional tolerance in height direction can achieve tolerance ≤1.0mm, other dimensional tolerances can reach ≤0.5mm
2. The surface is fully glazed to achieve maximum reflectivity and easy to clean
3. The reflectivity reaches 97% at the wavelength of 600-1000nm
4. The reflectivity exceeds 95% in the wavelength range of 380-1100nm
5. The body has proper porous and high strength characteristics
Main physical characteristics:
Material: Al2O3
Color: White
Density: 3.1Mg/m⊃3;
Porosity: 22%
Flexural strength: 170Mpa
Thermal expansion coefficient: 7.9×10-6--/С（200～500℃）
9×10-6/С（200～1000℃）
