  • Laboratory Glassware 5ml to 5000ml Quartz Distillation flask branch angle 75
  • Laboratory Glassware 5ml to 5000ml Quartz Distillation flask branch angle 75
Laboratory Glassware 5ml to 5000ml Quartz Distillation flask branch angle 75 Laboratory Glassware 5ml to 5000ml Quartz Distillation flask branch angle 75

Laboratory Glassware 5ml to 5000ml Quartz Distillation flask branch angle 75

  • Material:Synthetic fused silica,Flame fused quartz,Electrically fused quartz
  • Working Temperature:<1450 ℃
  • MOQ: No limited
  • SiO2 Purity: 99.99%
  • Quartz Distillation flask  , Laboratory conical flask  , fermentation and atmospheric distillation  , quartz glass flask
    Inquiry Send Email

    Description

    Laboratory Glassware 5ml to 5000ml Quartz Distillation flask branch angle 75


    Specification & Properties

    SiO2
    99.99%
    Density
    2.2g/cm3
    Compressive Strength
    1100Mpa
    Young's Modulus
    72000Mpa
    Modulus of Rigidity
    31000Mpa
    Mohs Hardness
    6.6
    Transformation Point
    1280°C
    Softening Point
    1780°C
    Annealing Point
    1250°C
    Specific Heat (20 ~ 350 °C)
    670J/kg.°C
    Thermal Conductivity (20 °C)
    1.4W/m.°C
    Index of Refraction
    1.4585
    Thermal Processing Temperature
    1750~2050°C
    Short-term Working Temperature
    1300°C
    Long-term Working Temperature
    1100°C
    Strain
    1270 C Fused The Quartz Glass Brick
    PPM Grade
    Controlled 10/20/100 PPM
    Electrical Resistivity: 1000℃
    1x106 Ω. cm


    Dimension


    Volume

    (ml)

    Height

    (mm)

    Ball OD

    (mm)

    Neck OD

    (mm)

    Side tube length

    (mm)

    Side tube OD

    (mm)

    50

    150

    54

    20

    80

    7

    100

    175

    65

    21

    100

    7

    250

    220

    88

    28

    140

    8

    500

    270

    110

    30

    170

    8.5

    1000

    330

    140

    36

    190

    9.5

    2000

    400

    175

    43.5

    250

    11.5

    3000

    450

    197

    49.5

    250

    13.5

    5000

    505

    235

    53.5

    270

    15

    10000

    600

    293

    65

    270

    15

    Note

    Flasks can also be customized, pls kindly send us detail requirement.
    Application
    Widely Used in the chemical industry,petrochemical industry,electronic chemistry,biochemical pharmaceuticals and in laboratory.
