Description
Product Details
Lamp Flow Tube For Laser Pumping Cavity
The samarium doped glass can block all UV light below 400nm, it is very good UV filter. Samarium doped glass can fluoresce in the visible range, which causes some increase in pumping efficiency with lasing mediums. It also can block the 1064nm wavelength.
By CNC machining, we can create different shapes and dimensions of laser flow tubes.
Flowtubes and Filter Flowtubes combine and integrate in one solid optical element attributes and technical characteristics necessary to perform simultaneously the following functions:
● cooling duct for both lamp(s) and laser rod(s);
● Filtering-absorbing undesired UV radiation, thus protecting the rod from long term solarizat
● Attenuating “lateral depumping” effects i.e. energy losses caused by the rod’s side emission, by absorbing it and preventing its backreflection.
Flowtubes satisfy only the first of the above functions while Filter Flowtubes may satisfy the first two or all three of them. This last category is of increasing interest for Nd:YAG Q-Switched lasers. For this case, Samarium doped Glass is the material of choice because it attenuates lateral depumping effects, thus avoiding super luminescence phenomena and absorbing undesired UV radiation.
Materials
We have following materials available to choose:
Quartz
Pyrex Glass
Borosilicate glass
Cerium doped quartz
Samarium doped glass (Sm2O3 Doped Glass)
Cerium- and Samarium-doped Filter Glasses
Silver and/or other metallic coatings flow tube
Advantages
Adapted edge cladding glasses on request.
Possibility for chemical strengthening in order to increase resistance to breakage due to thermal shock.
Completely customized designs and strict size control are possible.
Lamp Flow Tube For Laser Pumping Cavity
The samarium doped glass can block all UV light below 400nm, it is very good UV filter. Samarium doped glass can fluoresce in the visible range, which causes some increase in pumping efficiency with lasing mediums. It also can block the 1064nm wavelength.
By CNC machining, we can create different shapes and dimensions of laser flow tubes.
Flowtubes and Filter Flowtubes combine and integrate in one solid optical element attributes and technical characteristics necessary to perform simultaneously the following functions:
● cooling duct for both lamp(s) and laser rod(s);
● Filtering-absorbing undesired UV radiation, thus protecting the rod from long term solarizat
● Attenuating “lateral depumping” effects i.e. energy losses caused by the rod’s side emission, by absorbing it and preventing its backreflection.
Flowtubes satisfy only the first of the above functions while Filter Flowtubes may satisfy the first two or all three of them. This last category is of increasing interest for Nd:YAG Q-Switched lasers. For this case, Samarium doped Glass is the material of choice because it attenuates lateral depumping effects, thus avoiding super luminescence phenomena and absorbing undesired UV radiation.
Specification：
|
Product
|
Lamp Flow Tube For Laser Pumping Cavity |
|
Outer diameter |
8mm-30mm |
|
Thickness of wall |
1-5mm |
|
Length |
20mm-150mm |
|
Surface |
Polished |
Materials
We have following materials available to choose:
Quartz
Pyrex Glass
Borosilicate glass
Cerium doped quartz
Samarium doped glass (Sm2O3 Doped Glass)
Cerium- and Samarium-doped Filter Glasses
Silver and/or other metallic coatings flow tube
Advantages
Adapted edge cladding glasses on request.
Possibility for chemical strengthening in order to increase resistance to breakage due to thermal shock.
Completely customized designs and strict size control are possible.
Fast delivery time.
