  1. Home
  2. PRODUCT SHOW
  3. Prisms, Lenses, Filters
  4. Pentagonal Prisms
  • Pentagonal Prisms
  • Pentagonal Prisms
  • Pentagonal Prisms
  • Pentagonal Prisms
Pentagonal Prisms Pentagonal Prisms Pentagonal Prisms Pentagonal Prisms

Pentagonal Prisms

  • Material: H-K9L / JGS1
  • Angle Tolerance: ±3′ / ±1′
  • Surface Flatness: λ/4@633nm
  • Surface Quality: 60/40
  • Penta prisms
    Inquiry Send Email

    Description

    Pentagonal prisms

    A pentagonal prism is a prism that accurately reflects 90° of incident light. The reflective surface is coated with aluminum to improve reflectivity. Pentagonal prisms can reflect different incident light at the same angle. This feature eliminates the need for precise positioning of the prism in practical applications. Therefore, the performance is better than a cemented part composed of two lenses. This prism is used in the viewfinder of a camera, and the pentagonal prism is suitable for image observation systems or measuring instruments.


    Specification

    Parameters
    Value
    Material
    H-K9L / JGS1
    Angle Tolerance
    ±3′ / ±1′
    Surface Flatness
    λ/4@633nm
    Surface Quality
    60/40
    Bevel
    0.3×45°

    Regular Dimensions

    Dimension (mm) (A=B=C)
    D (mm)
    Material
    5
    5.4
    H-K9L
    10
    10.8
    H-K9L
    15
    16.2
    H-K9L
    20
    21.6
    H-K9L
    25
    27.1
    H-K9L
    30
    32.5
    H-K9L
    35
    37.9
    H-K9L
    40
    43.3
    H-K9L
    45
    48.7
    H-K9L
    50
    54.1
    JGS1
    5
    5.4
    JGS1
    10
    10.8
    JGS1
    20
    21.6
    JGS1
    25
    27.1
    JGS1
