  • Factory customized U shape Quartz glass substrate for WDM
  • Factory customized U shape Quartz glass substrate for WDM
Factory customized U shape Quartz glass substrate for WDM Factory customized U shape Quartz glass substrate for WDM

Factory customized U shape Quartz glass substrate for WDM

  • Material: Fused Silica Quartz
  • Refractive index:1.43-1.48
  • Coefficient of linear expansion:(5.3~5.8)×10^(-7)
  • Working temperature:1100 degree
  • U or V shaped quartz rod  , Quartz substrate
    Inquiry Send Email

    Description

    Quartz glass substrate for WDM, U-shape quartz glass rod, quartz glass for Fiber optic passive components

    Application:
    U-shape quartz rod is used for the matching of fusion tapered optical communication passive components
    Used to make WDM, fiber combiner, optical isolator, etc.

    Regular dimension of the U-shaped quartz rods:

    NO Specification Tolerance
    OD/W A L h OD A L
    1 1.0/0.5 15-38 5-100 <(OD/2) ±0.03 ±5 ±0.2
    2 1.1/0.5
    3 1.3/0.55
    4 1.4/0.55
    5 1.5/0.5
    6 1.6/0.75
    7 1.8/0.7
    8 2.0/1.2
    9 2.5/1.6
    10 3.5/2.0
    11 Other size According to requirement



    The Main Properties of Quartz Glass:
    Mechanical properties
    Quartz glass is a brittle material with low tensile strength and high compressive strength. The latter is 20 times that of the former.
    Thermal performance
    Quartz glass has a very low coefficient of linear expansion, very good resistance to thermal vibration, and is a poor conductor of heat.
    Optical performance
    An important difference between quartz glass and ordinary glass is its good transmittance in the entire spectrum, especially in the ultraviolet and deep ultraviolet spectrum, which is not available in ordinary optical glass.
    Electrical performance
    The main electrical properties of quartz glass are high dielectric electric field strength, low dielectric loss and low conductivity.
    Chemical properties
    Quartz glass is a material with very good chemical stability and does not react with water, salt solutions and most acids.
    Radiation resistance
    Compared with ordinary glass, quartz glass has excellent radiation resistance. Among them, synthetic quartz glass has the best radiation resistance and hardly produces color centers.
