Description
High precision fiber optic micron capillary glass tube
Precision borosilicate glass capillary tube can be cut to length precision glass borosilicate tubing and rod and used in fiber optical applications as connector ferrules and collimators.
Specification sheet:
|
SN |
OD(mm) |
ID(mm) |
Length(mm) |
|
1 |
1.01±0.03 |
0.31±0.04 |
11.2±0.1 |
|
2 |
1.6+0.01 |
1.005+0.01 |
4±0.1 |
|
3 |
1.796±0.005 |
0.95±0.05 |
4.9±0.1 |
|
4 |
1.8±0.01 |
1.025±0.005 |
4.0±0.1 |
|
5 |
2.2±0.01 |
1.025±0.005 |
4.0±0.1 |
|
6 |
2.2±0.005 |
1.6±0.01 |
4.0±0.1 |
|
7 |
2.76±0.01 |
1.81±0.005 |
9.0±0.1 |
|
8 |
2.78±0.01 |
1.81±0.005 |
8.0±0.1 |
|
9 |
2.78±0.03 |
1.885±0.015 |
8.5±0.1 |
|
10 |
2.976±0.01 |
1.808±0.04 |
12±0.1 |
|
11 |
3.0±0.1 |
2.0±0.03 |
19±0.1 |
|
12 |
3.0±0.05 |
1.8+0.05 |
4±0.1 |
|
13 |
3.05±0.01 |
1.81±0.005 |
8.0±0.1 |
|
14 |
3.2±0.02 |
1.812±0.005 |
9.0±0.1 |
|
15 |
3.3±0.1 |
1.81±0.005 |
3.0±0.1 |
|
16 |
3.3±0.05 |
2.07±0.06 |
7.5±0.02 |
|
17 |
3.37±0.02 |
2.812±0.005 |
9.0±0.1 |
|
18 |
3.5±0.02 |
1.81±0.005 |
4.7±0.1 |
|
19 |
3.5±0.1 |
2.5+0.05 |
3.5±0.1 |
|
20 |
3.6±0.05 |
3.0+0.05 |
9±0.1 |
|
21 |
3.7±0.02 |
1.81±0.005 |
4.7±0.1 |
|
22 |
3.7±0.05 |
2.607±0.005 |
4.7±0.1 |
|
23 |
4.0±0.01 |
2.415±0.005 |
11.5±0.02 |
|
24 |
4.1±0.05 |
2.807±0.005 |
4.7±0.1 |
|
25 |
4.13±0.03 |
2.88±0.02 |
16±0.1 |
|
26 |
4.1±0.1 |
2.8+0.05 |
3±0.1 |
|
27 |
4.2±0.05 |
2.93±0.01 |
17.0±0.1 |
|
28 |
4.4±0.02 |
1.8±0.02 |
1.9±0.1 |
|
29 |
4.45±0.05 |
3.3±0.01 |
16±0.1 |
|
30 |
4.6±0.02 |
3.05±0.007 |
15±0.1 |
|
31 |
4.6±0.03 |
3.6±0.02 |
19±0.1 |
|
32 |
4.9±0.02 |
3.1±0.02 |
5±0.05 |
|
33 |
6.8±0.03 |
4.04±0.02 |
4±0.1 |
|
34 |
9.9 |
6.84±0.03 |
3±0.1 |
